Model

BK-FD10S

BK-FD10P

BK-FD10T

BK-FD10PT

Type

Standard chamber

Standard chamber with 8 port manifold

Stoppering chamber

Stoppering
chamber with

8 port manifold

Freeze Drying Area

0.12 m2

0.09 m2

Tray

4 pcs

3 pcs

Height Between Trays

50mm

68mm

Cold Trap Temperature

≤-60℃

Cold Trap Capacity

9.5L

Cold Trap Size (Diameter*H)

Φ215*260mm

Vacuum Degree

<10 Pa

Water Capture Capacity

3kg/24h

Tray Size (D*H)

Φ200*20mm

Φ180*20mm

Freeze Drying Time

24h

Loading Capacity/Shelf (Liquid)

0.3L

Total Loading Capacity (Liquid)

1.2L

0.9L

Drying Chamber Size (Diameter*H)

Φ260*310mm

Φ260*450mm

Total Qty. Of Vial Φ22

260

195

Total Qty. Of Vial Φ16

480

360

Total Qty. Of Vial Φ12

920

690

Refrigerant

R600a+R290+R23

Cooling System

Air cooling

Power Supply

220V/50Hz,60Hz (single phase)

110V/60Hz (single phase)

Power Consumption

1.3KW

Power Supply

AC220V, 50/60Hz (single phase); 110V, 60Hz (single phase)

Standard Accessory

Vacuum pump 2L/S, 8m3/h (for all models)

Conical-mouth flask 500ml*8 pcs (only for model BK-FD10P/PT)

Optional Function & Accessory

Conical-mouth flask and wide-mouth flask(for BK-FD10P/PT)

Import vacuum pump

External Size (W*D*H)

640*610*550/810mm

640*610*550/950mm

640*610*550/990mm

Package Size(W*D*H)mm/

Gross Weight

Main Body

720*705*730(85kg)

Drying Chamber

/Vacuum Pump

705*590*530

(50kg)

705*590*530

(55kg)

705*590*530

(60kg)

720*705*730

(65kg)
